| Loading Table of SHERA Floor Board – One-way Slab (Calculation*) | ||||||||
|---|---|---|---|---|---|---|---|---|
| Distribution Load (kg/sq m) — Joist spacing for one-way slab calculated with safety factor of 2.5 | ||||||||
| Thickness of SHERA Board | 30 cm | 40 cm | 50 cm | 60 cm | 80 cm | 100 cm | ||
| 15 mm | 1766 | 993 | 636 | 441 | 248 | 159 | ||
| 16 mm* | 2009 | 1130 | 723 | 502 | 282 | 181 | ||
| 18 mm | 2542 | 1430 | 915 | 636 | 358 | 229 | ||
| 20 mm | 3139 | 1766 | 1130 | 785 | 411 | 282 | ||
| 25 mm | 4904 | 2759 | 1766 | 1226 | 690 | 441 | ||
| Concentrated Load (kg/area) — Joist spacing for one-way slab calculated with safety factor of 2.5 | ||||||||
| Thickness of SHERA Board | 30 cm | 40 cm | 50 cm | 60 cm | 80 cm | 100 cm | ||
| 15 mm | 318 | 238 | 191 | 159 | 119 | 95 | ||
| 16 mm* | 362 | 271 | 217 | 181 | 136 | 108 | ||
| 18 mm | 458 | 343 | 275 | 229 | 172 | 137 | ||
| 20 mm | 565 | 424 | 339 | 282 | 212 | 169 | ||
| 25 mm | 883 | 662 | 530 | 441 | 331 | 265 | ||
| Loading Table of SHERA Floor Board – Two Ways Slab (Calculation*) | ||||||||
| Distribution Load (kg/sq m) — Joist spacing for two-ways slab calculated with safety factor of 2.5 | ||||||||
| Thickness of SHERA Board | 30x30 cm | 30x40 cm | 30x60 cm | 40x40 cm | 40x60 cm | 40x120 cm | 60x60 cm | 60x120 cm |
| 15 mm | 2835 | 2407 | 2122 | 1595 | 1294 | 1113 | 709 | 531 |
| 16 mm* | 3226 | 2739 | 2414 | 1814 | 1472 | 1267 | 806 | 604 |
| 18 mm | 4082 | 3466 | 3056 | 2296 | 1863 | 1603 | 1021 | 764 |
| 20 mm | 5040 | 4280 | 3773 | 2835 | 2300 | 1979 | 1260 | 943 |
| 25 mm | 7875 | 6687 | 5895 | 4430 | 3594 | 3093 | 1969 | 1474 |
| Concentrated Load (kg/area) — Joist spacing for two-ways slab calculated with safety factor of 2.5t | ||||||||
| Thickness of SHERA Board | 30x30 cm | 30x40 cm | 30x60 cm | 40x40 cm | 40x60 cm | 40x120 cm | 60x60 cm | 60x120 cm |
| 15 mm | 510 | 433 | 382 | 383 | 311 | 267 | 255 | 191 |
| 16 mm* | 581 | 493 | 435 | 435 | 353 | 304 | 290 | 217 |
| 18 mm | 825 | 714 | 640 | 596 | 492 | 430 | 385 | 293 |
| 20 mm | 1019 | 882 | 790 | 736 | 608 | 531 | 476 | 362 |
| 25 mm | 1411t | 1204 | 1061 | 1063 | 863 | 742 | 709 | 531 |
| * Made-to-order product | ||||||||
| Remark: - This Load Table already included Safety Factor 2.5 - This Table base on Dry Condition - Point Load are determine in the effective area of 10cm x 10cm footprint | ||||||||
| SR NO | Description | Value |
|---|---|---|
| 01 | Test Standard | IS 14862: 2000 |
| 02 | Category | Type A sheet (Category 3) |
| 03 | Thickness Tolerance | Pass |
| 04 | Density | 1350 ± 50 kg/m³ |
| 05 | Modulus of Rupture / Flexural Strength | >18 N/mm2 (EMC Condition) |
| 06 | Moisture Content | <5% |
| 07 | Water Absorption | <30% |
| 08 | Water Impermeability | Pass |
| 09 | Thermal Conductivity | 0.15 W/m°K |
| 10 | Moisture Movement | 0.04% |
| 11 | Compression Indention / Falling Ball Impact / Impact Indention Test | <0.1 mm Indention |
| 12 | Combustibility / Building Combustibility | Non-Combustible |
| 13 | Ignitability | Pass |
| 14 | Fire Propagation Index | I = 0.4 |
| 15 | Surface Spread of Flame | Class1 |
| SR NO | Properties | Value |
|---|---|---|
| 01 | Test Standard | IS 14862: 2000 |
| 02 | Category | Type A sheet (Category 3) |
| 03 | Thickness Tolerance | Pass |
| 04 | Density | 1350 ± 50 kg/m³ |
| 05 | Modulus of Rupture / Flexural Strength | >10 N/mm2 (EMC) |
| 06 | Moisture Content | <5% |
| 07 | Water Absorption | <30% |
| 08 | Water Impermeability / Tightness | Pass |
| 09 | Thermal Conductivity | 0.156 W/m°K |
| Product Category | Texture | Width (mm) | Length (mm) | Thickness | Profile | Weight (kg/pc) |
|---|---|---|---|---|---|---|
| Board (Uncolored) | Plain | 1220 | 2440 | 4.5 mm | Square Cut Edge | 20.9 |
| 1220 | 2440 | 6 mm | Square Cut Edge / Recessed Edge | 27.91 / 27.66 | ||
| 1220 | 2440 | 8 mm | Square Cut Edge / Recessed Edge | 37.26 / 35.74 | ||
| 1220 | 2440 | 10 mm | Square Cut Edge | 46.58 | ||
| 1220 | 2440 | 12 mm | Square Cut Edge | 55.89 | ||
| 1220 | 2440 | 15 mm | Square Cut Edge | 69.32 | ||
| Plain | 1220 | 2440 | 18 mm | Square Cut Edge | 83.84 | |
| Deco Board (Uncolored) | Cassia | 1220 | 2440 | 6 mm | Square Cut Edge | 27.91 |
| Cassiano | 1220 | 2440 | 6 mm | Square Cut Edge | 27.91 | |
| Cassia | 1220 | 2440 | 8 mm | Square Cut Edge | 37.26 | |
| Cassiano | 1220 | 2440 | 8 mm | Square Cut Edge | 37.26 | |
| Straight Grain V groove 3" | 1200 | 2400 | 6 mm | V-Groove | 26.42 | |
| Straight Grain V groove 4" | 1200 | 2400 | 8 mm | V-Groove | 35.59 | |
| Brick | 1220 | 2440 | 6 mm | Square Cut Edge | 27.91 | |
| Blossom | 1220 | 2440 | 6 mm | Square Cut Edge | 27.91 | |
| Drop | 1220 | 2440 | 6 mm | Square Cut Edge | 27.91 | |
| Rocco | 1220 | 2440 | 6 mm | Square Cut Edge | 27.91 | |
| Stucco | 1220 | 2440 | 6 mm | Square Cut Edge | 27.91 | |
| Teak Plank (Precolored) | Golden Sand | 150 | 3000 | 8 mm | Square Cut Edge | 5.40 |
| Walnut | 150 | 3000 | 8 mm | Square Cut Edge | 5.40 | |
| Afromosia | 150 | 3000 | 8 mm | Square Cut Edge | 5.40 | |
| Shine Light Golden Teak | 150 | 3000 | 8 mm | Square Cut Edge | 5.40 | |
| Shine Light Brown Teak | 150 | 3000 | 8 mm | Square Cut Edge | 5.40 | |
| Modern Grey | 150 | 3000 | 8 mm | Square Cut Edge | 5.40 | |
| Plank (Uncolored) | Antique Wood | 150 | 3000 | 8 mm | Square Cut Edge | 5.40 |
| Teak | 150 | 3000 | 8 mm | Square Cut Edge | 5.40 | |
| Cassia | 150 | 3000 | 8 mm | Square Cut Edge | 5.40 | |
| Straight Grain | 150 | 3000 | 8 mm | V-Cut Edge | 5.40 | |
| Plank (Uncolored) | Cassia | 150 | 3000 | 10 mm | Yellow Flame | 5.65 |
| Splendid Plank (Uncolored) | Smooth | 220 | 3000 | 10 mm | DL02 | 8.60 |
| Smooth | 220 | 3000 | 10 mm | DL05 | 8.12 | |
| Smooth | 220 | 3000 | 10 mm | DX12 | 8.44 | |
| Floor Plank (Uncolored) | Cassia | 150 | 3000 | 16 mm | V-Groove | 11.18 |
| Skirt (Uncolored) | Plain | 75 | 3000 | 12 mm | Modern | 4.05 |
| Plain | 100 | 3000 | 12 mm | Modern | 5.33 | |
| Door Frame (Uncolored) | - | 700 | 2100 | Cross Section | Classic | 24.07 |
| 800 | 2100 | 100 x 35 | Classic | 24.56 | ||
| 900 | 2100 | - | Classic | 25.06 |
| Product | Applications |
|---|---|
| SHERA PRO Board (Advanced High-Performance Fibre Cement Boards) | Façade, External Ceilings, Wall Solutions, Flooring, Landscaping, CNC Cutting, Roof Underlay |
| SHERA Plank | Internal Cladding, External Cladding, Landscaping, False Ceilings |
| SHERA Deco Board | Wall Partitions, False Ceilings, Wall Cladding, External Cladding, Landscaping |
| SHERA Splendid Plank | Internal Cladding, External Cladding, Landscaping |
| SHERA Floor Plank | Flooring, Pargola, Stairs, Outdoor Furniture, Fin Application, Fence |
| Product Category | Texture | Width (mm) | Length (mm) | Thickness | Profile | Weight (kg/pc) |
|---|---|---|---|---|---|---|
| Board | Plain | 1220 | 2440 | 6 mm | Square Cut Edge | 28.10 |
| 8 mm | 37.46 | |||||
| 10 mm | 46.83 | |||||
| 12 mm | 56.19 | |||||
| 15 mm | 70.24 | |||||
| 18 mm | 84.29 |
